Description
Encryption
256-bit AES keys and RSA algorithms
FBI / Image Certifications
FBI Appendix F-certified, Mobile ID IQS FAP 50, GSA FIPS201
Speed
Min frame rate slaps > 7.7FPS
Min frame rate rolls > 10FPS
API Interface
Capture single-finger/four-finger direct, single-finger rolls, multidevice / multi-thread support
Quality Scoring
NFIQ v1 supported on all OSes and NFIQ2 for Windows
Sensor Type
LES
Camera
TFT
Resolution
500 ppi
Grayscale
256 grayscale dynamic range
Image Size
1600 x 1000 pixels
Supported Image Formats
RAW, JPEG2000, BMP, PNG, WSQ (FBI-approved)
Product Weight
191.6 grams / 0.4 lbs (not including cable)
Platen Size
85.8 mm x 53.9 mm / 3.3” x 2.1”
Sensing Area
81.2 mm x 50.8 mm / 3.2” x 2.0”
Scanner Assembly Dimensions
113.4 mm x 82.9 mm x 17.2 mm / 4.4” x 3.2” x 0.6” | Desktop
110.4 mm x 79.9 mm x 16.2 mm / 4.3″ x 3.1″ x 0.6″ | Embedded
Interface
USB 2.0
Power Source
USB Host
USB Voltage Level
4.4V to 5.25V
